Application

MULTISTAR offers 1PC, 2PC, 3PC-5PC steel wheels for heavy-duty lift trucks, reach stackers, cargo handling vehicles and gantry cranes. Material handling wheels are TRA and ETRTO compliant; and rated for ultra-heavy loads, making them a preferred choice for OEMs.

Inquire Now

8"
9"
10"
12"
15"
16“
16.5”
18“
20”
24“

		Stud Holes					Thickness
Rim Size	Fitted tyre	No.	Dia.	PC Dia.	Center Hole Dia.	Offset/ET.	Rim	Disc	Model No.
2.50C-8	4.00-8	4	10.5	110	70			3	803404001
3.00D-8	4.00-8	6	14.5	148	106	0		4	803404002
3.00D-8	4.00-8	6	15	125	100	0		5	803404003
3.00D-8	5.00-8	6	14.5	148		0		5	803404004
3.50D-8	5.00-8	6	15	125		0		5	803404005
4.33R-8	18X7-8	6	13.2	148		0		4	803404006
4.33R-8	16X6-8 18X7-8	5	18.5	145	110	25		10	803404007
4.33R-8 3pc	16X6-8 18X7-8	6	14.5	148	110	15		9	803404008
3.00D-8	4.00-8 5.00-8 15X4 1/2-8	5	18.5	114.3	80	27		10	803404009
5.5x8	16x6.5-8	4	14	101.6	72	-2	2	5	803404010

		Stud Holes					Thickness
Rim Size	Fitted tyre	No.	Dia.	PC Dia.	Center Hole Dia.	Offset/ET.	Rim	Disc	Model No.
3.50W-9		6	16.8	166		0		6	803404011
3.70R-9		6	17	175	140	0		5	803404012
4.00E--9	6.00-9	8	16	160		0		5	803404013
4.00E--9	6.00-9	6	17	170	140	0		5	803404014
4.00E--9	6.00-9	6	18	170	140	0		5	803404015
4.00E--9	6.00-9	6	17.5	180		0		5	803404016
4.33R-9	7.00-9	6	16.5	145	105	0		4	803404017
4.33R-9	7.00-9	6	16.5	145	105	0		5	803404018
5.00S-9	7.00-9	6	16.5	170		0		5	803404019

		Stud Holes					Thickness
Rim Size	Fitted tyre	No.	Dia.	PC Dia.	Center Hole Dia.	Offset/ET.	Rim	Disc	Model No.
5.00F-10	6.50-10 7.50-10	5	21.5	160	110	9		10	803404020
6.50-10	23X8-10 23X9-10 200/50-10	5	18.5	145	110	7.5		10	803404022
5.00F-10	6.5-10	8	16	160	130	0		5	803404023
5.00F-10	6.5-10	6	17.5	180	150	0		5	803404024
5.00F-10	6.5-10	6	17.5	180	150	0		6	803404025
5.00F-10 4pc	6.5-10	6	13.5	139	110	0		12	803404026
6.5-10	23X9-10	5	15	145	110	32		6	803404027
6.5-10	23X9-10	6	28	142	102.5	35		6	803404028
6.50F-10	23X8/9-10	6	18.5	188	145			6	803404029

		Stud Holes					Thickness
Rim Size	Fitted tyre	No.	Dia.	PC Dia.	Center Hole Dia.	Offset/ET.	Rim	Disc	Model No.
5.00S-12	7.00-12 8.25-12	14	16	210	178	60		10	803404030
8.00G-12	27X10-12	14	16	210	178	28		12	803404031
8.00G-12	23X10-12NHS	6	20	220	160	8.5		12	803404032
8.00G-12	27X10-12NHS							NO DISC	803404033
4.50E-12	5.50-12	4	17	170	135	0		3	803404034
5.00S-12	7.00-12	6	14.5	180	150	0		5	803404035
5.00S-12	7.00-12	6	32	220	151	0		6	803404037
5.00S-12	7.00-12	6	27	200	150	0		6	803404038
5.00S-12	7.00-12	5	32	210	158	0		6	803404039
5.00S-12	7.00-12	6	27	220	170	0		6	803404040
5.00S-12 4pc	7.00-12	8	27	190	145	70		12	803404041
5.00E-12		4	17	170	135	0		6	803404042
6.50F-12	8.25-12	8	14	186	155	0		6	803404043
6.50F-12	8.25-12	5	32	225	180	0		6	803404044
8.00G-12	27X10-12	6	27	200	150	0		6	803404045
8.0-12	27X10-12	10	26	225	176	-6		10	803404046

		Stud Holes					Thickness
Rim Size	Fitted tyre	No.	Dia.	PC Dia.	Center Hole Dia.	Offset/ET.	Rim	Disc	Model No.
6.00GS-15	7.50-15	10	26	225	176	123		12	803404047
6.00GS-15	7.50-15	10	32	225	171	123		12	803404048
6.50-15	8.25-15	6	32	220	165	77		12	803404049
6.50-15	8.25-15	6	32	250	200	74		12	803404050
6.50-15	8.25-15	10	32	290	240	135		12	803404051
6.50-15	8.25-15	8	32	290	240	135		12	803404052
6.50-15	8.25-15	8	21.5	230	190	31.5		12	803404053
6.50-15	8.25-15	10	26	255	176	139		12	803404054
6.50-15	8.25-15	6	32	222	161	-10		12	803404055
6.50-15	8.25-15	8	32	290	240	128.5		12	803404056
6.50-15	8.25-15	8	32	260	199	33		12	803404057
6.50-15	8.25-15	6	32	222	162	78		12	803404058
7.00T-15	28X9-15	6	32	200	150	77		10	803404059
7.00T-15	28X9-15	5	21.5	225	180	-5		10	803404060
7.00T-15	28X9-15	6	23	220	180	-20		10	803404061
7.00T-15	28X9-15	8	26	210	165	0		10	803404062
7.00T-15	28X9-15	6	32	220	170	0		10	803404063
7.00T-15	28X9-15	8	26	190	145	0		10	803404064
7.50V-15	250-15	8	32	200	150	70		12	803404065
7.50V-15	250-15	6	24	250	200	90		12	803404066
8.00V-15	300-15	6	32	250	200	70		10	803404067
8.00V-15	300-15	6	32	222	165			12	803404068
9.00-15	315/70-15	8	24	275	221	15		12	803404069
9.75-15	355/65-15	10	26	225	176	25		12	803404070
11.00-15	22X13-15	10	26	225	175	-7		12	803404071

		Stud Holes					Thickness
Rim Size	Fitted tyre	No.	Dia.	PC Dia.	Center Hole Dia.	Offset/ET.	Rim	Disc	Model No.
6.50-16	8.25-16	6	Φ32	220	165	77		12	803404072
7.00T-16	9.00-16	5	21.5	225	178	0		12	803404073
7.00T-16	9.00-16	5	21.5	225	178	135		12	803404074
7.00T-16	9.00-16	6	32	260	200	82		12	803404075

		Stud Holes					Thickness
Rim Size	Fitted tyre	No.	Dia.	PC Dia.	Center Hole Dia.	Offset/ET.	Rim	Disc	Model No.
8.25x16.5	10.00-16.5	5		140	94	0			803404076
8.25x16.5	10.00-16.5	6		205	161	0			803404077
8.25x16.5	10.00-16.5	8		203.2	152.4	0			803404078
9.75x16.5	12.00-16.5	6		205	161	0			803404079
9.75x16.5	12.00-16.5	8		203.2	152.4	0			803404080
9.75x16.5	12.00-16.5	8		275	221.25	-13			803404081
12.00x16.5	33/15.50-16.5	9		241.3	201.6	0			803404082
12.00x16.5	33/15.50-16.5	8		203.2	152.4	11			803404083

		Stud Holes					Thickness
Rim Size	Fitted tyre	No.	Dia.	PC Dia.	Center Hole Dia.	Offset/ET.	Rim	Disc	Model No.
7.00-18		8	17	203.2	153	0		12	803404084

		Stud Holes					Thickness
Rim Size	Fitted tyre	No.	Dia.	PC Dia.	Center Hole Dia.	Offset/ET.	Rim	Disc	Model No.
6.50-20	8.25-20	6	32	415	355	125		12	803404085
6.50-20	8.25-20	8	32	380	324	125		12	803404086
6.50-20	8.25-20	10	32	290	240	138.5		12	803404087
7.00T-20	9.00-20	12	32	404	353	135		12	803404088
7.00T-20	9.00-20	8	32	415	335	157		12	803404089
7.00T-20	9.00-20	10	32	390	340	143		12	803404090
7.00T-20	9.00-20	8	32	335	281	30		12	803404091
7.50V-20	10.00-20	10	23	Φ335	Φ281	0		12	803404092
8.00-20	12.00R20	8	17.2	203.2	153	-34		12	803404093
8.00-20	12.00R20	8	20.5	275	221	21.6		12	803404094
8.00-20	12.00R20	10	26	335	281	102		12	803404095
8.50-20	12.00-20	10	23	335	281	33.3		12	803404096
8.50-20	12.00-20	16	24	370	320	187		12	803404097
10.00-20	14.00-20	10	26	335	281	70		16	803404098
11.00-20	15.00-20	9	18	242	202	-40		16	803404099

		Stud Holes					Thickness
Rim Size	Fitted tyre	No.	Dia.	PC Dia.	Center Hole Dia.	Offset/ET.	Rim	Disc	Model No.
8.50-24	12.00R24	10	30	335	281	0		16	803404100
8.50-24	12.00R24	8	27	275	221	0		16	803404101
8.50-24	12.00R24	16	26	400	350	200		16	803404102
10.00-24	14.00-24	12	24	425	371	195		16	803404103
10.00-24	14.00-24	10	26	335	281	0		16	803404104
10.00-24	14.00-24	24	26	425	371	198		16	803404105

Not all items are listed in this catalog. Please contact us for any application you do not see in this catalog.
